Features /
1.Can be used with all hydraulic liner hangers.
2.After the liner wiper plug latches into the landing collar, sealing is established and holds back pressure. 3.Good resistance to erosion allows long time and large flow rate circulation. 4.All internal parts are made of easily-drillable materials. |
|
Size |
Casing |
Shear stress |
||
|
in |
mm |
Weight Ib/ft |
Wall thickness mm |
MPa |
|
4 1/2 |
114.3 |
9.50-15.10 |
5.21-8.56 |
17-20 |
|
5 |
127.0 |
13.00-21.40 |
6.43-11.10 |
|
|
5 1/2 |
139.7 |
14.00-26.80 |
6.20-12.70 |
|
|
6 5/8 |
168.3 |
20.00-32.00 |
7.32-12.06 |
|
|
7 |
177.8 |
20.00-38.00 |
6.91-13.72 |
|
|
7 5/8 |
193.7 |
26.40-47.10 |
8.33-15.68 |
|
|
8 5/8 |
219.1 |
24.00-49.00 |
6.71-14.15 |
|
|
9 5/8 |
244.5 |
32.30-58.40 |
7.92-15.11 |
|
|
10 3/4 |
273.1 |
32.75-73.2 |
7.09-17.07 |
|
|
11 3/4 |
298.5 |
42.00-71.00 |
8.46-14.78 |
|
|
13 3/8 |
339.7 |
48.00-72.00 |
8.38-13.06 |
|
|
16 |
406.4 |
65.00-109.00 |
9.52-16.66 |
|
